Size and weight |
Width |
480 mm |
18-15/16 inches |
Depth |
482 mm |
19 inches |
Height |
136 mm |
5-3/8 inches |
Weight |
9.8 kg |
21 lbs. 10 oz. |
 |
Maximum Polyphony |
64 voices |
Wave Memory Slot |
1 (168pin DIMM PC66/100/133 CL2/3) |
Projects |
Unlimited (depends on the space of HDD) |
Samples |
Max 9,998 per project |
Songs |
Max 16 songs per project |
Patches |
Max 16 per song (called INSTRUMENTS) |
Partials |
Max 96 per PATCH |
Audio Phrases |
Max 512 (16 pads x 32 banks) per project |
Signal Processing |
AD Conversion |
24 bits, 64times oversampling |
DA Conversion |
24 bits, 128times oversampling |
Data Format |
16 bits (linear) |
Sampling Rate |
44.1 kHz (fixed) |
Sampling Section |
Importable format |
Audio CD Windows(R) WAVE files AIFF files ACID WAVE files library from Sonic Foundry AKAI MPC Sound library Roland S-700 library |
Exportable format |
Audio CD Windows(R) WAVE files |
Memory Size |
128 MB (standard) or 512 MB (expanded) |
Sampling Time |
128 MB (standard) mono : 25 min.approx., stereo : 12 min.approx. 512 MB (expanded) mono : 101 min.approx., stereo : 50min.approx. |
Sequencer Section |
Type |
Linear Sequencer |
Tracks |
8 audio tracks for AUDIO PHRASES 128 MIDI tracks for both internal INSTRUMENTS and extenal 32 MIDI devices |
Max Events |
300,000 |
Recording Type |
Event Real-time / Event Step / Audio Direct |
Editing |
Event List Editor, Piano Roll Editor for MIDI event editing |
Others |
Recording Quantize / Play Quantize / Quick Loop / Audio Direct Recording |
Effects Section |
Effect Channels |
3 (2 loop effects + MFX) |
Loop Effects |
2 (Reverb and Delay/Chorus) |
MFX algorithms |
24 |
Others |
Mastering Tool Kit |
Pads |
Type |
16 Velocity Pads, aftertouch sensitive
|
Banks |
32 banks (AUDIO PHRASES) 6 banks x 16 part (PATCH) |
Storage Section |
HDD capacity |
40 GB
|
CD-R/RW drive |
Built in (Read : 32 times speed / Write : 8 times speed / Rewrite : 8 times speed) |
Others |
FDD (3.5 inch, 2DD or 2HD) USB for file transfer to PC/MAC |
Connectors |
Analog Input |
1 pair of MIC/LINE (1/4 inch TRS) 1 pair of PHONO (RCA pin type) |
Digital Input |
A (coaxial) / B (optical) / R-BUS on optional I/O expansion board |
Analog Output |
1 pair of Master Out (1/4 inch TRS) 1 Phones (Stereo 1/4 inch phone type) Multi Output (6 x 1/4inch TRS) on optional I/O expansion board |
Multi Output |
(6x1/4 inch TRS) on optional I/O expansion board |
Digital Output |
A (coaxial) / B (optical) |
USB port |
B type / USB 1.1 / Mass Storage Class |
MIDI |
IN / Out A / Out B |
Foot SW |
1/4 inch phone type |
Display |
320 x 240dots Graphic LCD (with backlight) |
Power Supply |
AC117V, AC230V or AC240V |
Accessories |
Owner's Manual Demonstration CD (CD-ROM) AC cord
|
Options |
DP-2 Foot Switch MV8-OP1 Audio I/O Expansion Expansion Memory (DIMM) |
Media and file format compatibility |
Import |
Audio CD |
audio |
CD-ROM |
.wav/AIFF, ACID wave files, S-700 Series, SMF |
USB |
.wav/AIFF, ACID wave files, AKAI MPC2000/4000, SMF |
Floppy disk |
AKAI MPC2000/4000, SMF |
Export |
Audio CD |
audio |
CD-ROM |
.wav, MV-8000 native data (Project etc.) |
